OSG USA, Inc. TP308720520 5.2 mm Dia. x 6 mm Shank x 26 mm Flute Length x 82 mm OAL, 3xD, EgiAs, 3 Flute, Coolant Thru, Solid Carbide Drill Online

Original price was: $137.28.Current price is: $34.32.

SKU: US-6728201666765 Categories: , Tag:

Description

OSG USA, Inc. TP308720520 5.2 mm Dia. x 6 mm Shank x 26 mm Flute Length x 82 mm OAL, 3xD, EgiAs, 3 Flute, Coolant Thru, Solid Carbide Drill

Short Description

OSG USA, Inc. 8720520 5.2 mm Dia. x 6 mm Shank x 26 mm Flute Length x 82 mm OAL, 3xD, EgiAs, 3 Flute, Coolant Thru, Solid Carbide Drill

Full Description

Drill Bit Size / Cutting Diameter (DC) 5.2 mm Cutting Edge Material Carbide
Drill Bit Size / Cutting Diameter (DC) – Metric 5.2 mm Tool Type Stub Drill
Length Group 3xD Measurement Type Metric
Coating EgiAs Series/List # 6600
Applicable Material Steel | Stainless Steel | Aluminum / Non-Ferrous Materials | Super-Alloys / Titanium | Hard Materials Usable Length (LU) 26 mm
Connection Diameter Machine Side (DCONMS) 6 mm Length Chip Flute (LCF) 26 mm
Coolant Supply Property (CSP) Coolant Thru Overall Length (OAL) 82 mm
Point Angle (SIG) 140 Degrees Flute Count (NOF) 3
Functional Length (LF) 26 mm Cutting Direction (HAND) Right Hand
